D-STAR

D-STAR uses reflector and module logic that should not be confused with DMR talkgroups. Verify the connector, module and local audio path before blaming the radio.

Reflectors get easier once the nouns stop moving around.

What it is

D-STAR is an open digital amateur-radio protocol established by JARL. Internet gateways can route digital voice through repeaters and other D-STAR infrastructure.

Where it fits at K6RCS

D-STAR is part of the broader K6RCS digital-network literacy layer even when the current physical-radio workflow may reach it through software or gateway systems rather than a dedicated D-STAR radio.

Identity and addressing

MYCALL	Your station callsign/identity.
RPT1 / RPT2	Local repeater/module and gateway routing fields.
URCALL	Destination/routing command depending on the operating case.
Reflector/module	Network conference destination and module letter.

Setup order

Register/verify the callsign where the intended gateway system requires it.
Program the local repeater and correct module deliberately.
Test local repeater access before adding reflector or gateway routing.
Use one known reflector/module as the first Internet test and confirm unlink behavior.

Test sequence: prove receive first, then local RF/audio, then the network connector, then the destination, and only then cross-mode or bridging. Change one layer at a time. The goal is to know which layer works, not to get one lucky connection.

Common failure modes

Padding/callsign-field formatting errors.
Confusing repeater module letters with reflector modules.
Leaving a reflector linked after the intended QSO or test.
Assuming a hotspot-generated D-STAR path behaves exactly like a local repeater gateway.

Security and privacy

Do not publish passwords, API keys, device UIDs, hotspot security values, local IP addresses, management URLs, or detailed behavioral schedules. Keep backups of known-good codeplugs/configurations, use unique credentials, and document firmware/software versions before changing them.

Primary sources and directories

Icom D-STAR introductionPrimary/reference source Icom D-STAR resourcesPrimary/reference source RadioID D-STAR repeater dataPrimary/reference source

Back to digital systems All operator resources

Save the reflector and module together

The module letter is part of the destination. REF014B and REF014C are not interchangeable merely because the reflector number matches.

Reflector	Current use	Handling
REF014 B	Team Stone default; SNARS Open D-STAR net Wednesday 6 PM	Retain as the normal meeting/default reference.
REF014 C	Ham Nation After Show Wednesday 7 PM; W6CX default reflector	Separate destination from 014B.
REF029 A	Western Digital D-STAR Saturday 7 PM	Save module A explicitly.
REF030 C	North America alternate	Retained Team Stone alternate/reach test.

For openSPOT use, select profile 4, choose the exact REF/XRF server and module, confirm connection status, use DN on the FT-5DR, listen, identify, and restore the normal meeting destination afterward.
